Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`si;E]
[ Si.E]
Math (1 to 8)
Source Instance E
Set the instance of the
function selected above.
1 to 250
1
2198
[offset 70]
0x7D (125)
1 to 8
0x0A (10)
- - - -
25010
uint
RWES
[`s2;E]
[ SZ.E]
Math (1 to 8)
Source Zone E
Set the zone of the function
selected above.
0 to 16
0
2208
[offset 70]
0x7D (125)
1 to 8
0x0F (15)
- - - -
25015
uint
RWES
[`S;Lo]
[ S.Lo]
Math (1 to 8)
Scale Low
If Math function is set to
Process or Deviation Scale,
this will scale Source A
low value to Range Low
setting.
-1,999.000 to 9,999.000
0.0
2226
[offset 70]
0x7D (125)
1 to 8
0x18 (24)
129
25024
float
RWES
[`S;hi]
[ S.hi]
Math (1 to 8)
Scale High
If Math function is set to
Process or Deviation Scale,
this will scale Source A
high value to Range High
setting.
-1,999.000 to 9,999.000
1.0
2228
[offset 70]
0x7D (125)
1 to 8
0x19 (25)
130
25025
float
RWES
[Unit]
[Unit]
Math (1 to 8)
Units
Set output units.
[`Src]
Source (1539)
[nonE]
None (61)
[`A;tP]
Absolute Tempera-
ture (1540)
[`r;tp]
Relative Tempera-
ture (1541)
[PWr]
Power (73)
[`pro]
Process (75)
[``rh]
Relative Humidty
(1538)
Source
2242
[offset 70]
0x7D (125)
1 to 8
0x20 (32)
- - - -
25032
uint
RWES
[`r;Lo]
[ r.Lo]
Math (1 to 8)
Range Low
If Math function is set to
Process or Deviation Scale,
this will output Source A
Scale Low value to Range
Low setting.
-1,999.000 to 9,999.000
0.0
2230
[offset 70]
0x7D (125)
1 to 8
0x1A (26)
131
25026
float
RWES
[`r;hi]
[ r.hi]
Math (1 to 8)
Range High
If Math function is set to
Process or Deviation Scale,
this will output Source A
Scale High value to Range
High setting.
-1,999.000 to 9,999.000
1.0
2232
[offset 70]
0x7D (125)
1 to 8
0x1B (27)
132
25027
float
RWES
[p;unt]
[P.unt]
Math (1 to 8)
Pressure Units
If Math function is set for
Pressure to Altitude units,
set units of measure for
conversion.
[`psi]
Pressure Units
(1671)
[pasc]
Pascal (1674)
[atm]
Atmosphere (1675)
[mbr]
mbar (1672)
[torr]
Torr (1673)
Pressure
Units
2238
[offset 70]
0x7D (125)
1 to 8
0x1E (30)
- - - -
25030
uuint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
