Watlow EZ-ZONE RME User Manual
Page 76
Watlow EZ-ZONE
®
RME Module
•
73
•
Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[sfn;B]
[SFn.B]
Special Output (1 to 4)
Source Function B
Set the type of function
that will be used for this
source.
[nonE]
None (61)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop
(73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[`uAr]
Variable (245)
None
6622
[offset 80]
0x87 (135)
1 to 4
2
184
35002
uint
RWES
[`si;B]
[ Si.B]
Special Output (1 to 4)
Source Instance B
Set the instance of the
function selected above.
1 to 250
1
6626
[offset 80]
0x87 (135)
1 to 4
4
185
35004
uint
RWES
[`s2;B]
[ SZ.B]
Special Output (1 to 4)
Source Zone B
Set the zone of the function
selected above.
0 to 16
0
6630
[offset 80]
0x87 (135)
1 to 4
6
- - - -
35006
uint
RWES
[Pon;A]
[Pon.A]
Special Output (1 to 4)
Power On Level 1
If Function is set to Com-
pressor Control:
Use Source A for a first
loop to inform the function
whether the compressor
will soon be required.
• Set Power On Level 1
and Power Off Level 1
to the Source A values
that will switch the
compressor on and off.
-100.00 to 100.00%
0
6654
[offset 80]
0x87 (135)
1 to 4
0x12 (18)
186
35018
float
RWES
[PoF;A]
[PoF.A]
Special Output (1 to 4)
Power Off Level 1
-100.00 to 100.00%
5
6656
[offset 80]
0x87 (135)
1 to 4
0x13 (19)
187
35019
float
RWES
[Pon;b]
[Pon.b]
Special Output (1 to 4)
Power On Level 2
If Function is set to Com-
pressor Control:
Use Source B for a second
loop to inform the function
whether the compressor
will soon be required.
• Set Power On Level 2
and Power Off Level 2 to
the Source B values that
will switch the compres-
sor on and off.
-100.00 to 100.00%
0
6658
[offset 80]
0x87 (135)
1 to 4
0x14 (20)
188
35020
float
RWES
[PoF;b]
[PoF.b]
Special Output (1 to 4)
Power Off Level 2
-100.00 to 100.00%
5
6660
[offset 80]
0x87 (135)
1 to 4
0x15 (21)
189
35021
float
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
