Variable Function
This function simply passes the stored value to its
output.
An error, when read, can indicate any of the following:
None, Open, Shorted, Measurement Error, Bad Cal
Data, Ambient Error, RTD Error, Fail, Math Error,
Not Sourced, Stale
A variable function block is used to store a user sup-
plied value and provide a source input to another
function block with that value. As an example, you
could use a variable function value as one input to
a compare function. The other input to the compare
function would determine the output value based on
the user's supplied value.
Variable
Overview
Instances - 8 per RME
Data
Type
Digital
Value
Analog
Value
[``o;u] Output Value : -1,999.000 to 9,999.000
or On, Off
[Unit] Units : None, Absolute Temperature,
Relative Temperature, Power,
Process, Relative Humidity
Unit
s
[tyPE] Data Type : Analog, Digital
[`Dig] Digital Value : On, Off
[AnLg] Analog Value : -1,999.000 to 9,999.000
[`uAr] Variable Menu
[`SEt] Setup Page
Output Value
Error
Variable
Digital
Data
Type
Digital
Value
Analog
Value Unit
s
Output Value
Error
Variable
Analog
Data
Type
Digital
Value
Analog
Value Unit
s
Output Value
Error
