Watlow EZ-ZONE ® RME Module • 104 • Chapter 6 Features
Math
Sample and Hold
Range Lo
w
Range High
Pressure Units Altitude Unit
s
Scale Lo
w
Scale High
Functio
n
Filter Offset Filter
Math
Dewpoint
Range Lo
w
Range Hig
h
Pressure Units Altitude Unit
s
Scale Lo
w
Scale High
Functio
n
Filter Offset Filter
If E = OFF, Output Value = Filter [A + Offset]
If E = ON, Output Value = Filter [last value of A + Offset]
Display units follows Source A
Output Value = Filter [427.26 * (CP * B / 8.8618)
/ (17.27- (CP * B / 8.8618)) + 32 + Offset]
Source A is used for Calculated Pressure or CP ;
Note: For dewpoint, Source A is temperature (F)
and Source B is RH (%). Saturation pressure
calculation is identical to that used in wet/dry
bulb. Result is in degrees F.
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Source Function C
Source Instance C
Source Zone C
Source Error C
Source Function D
Source Instance D
Source Zone D
Source Error D
Source Function E
Source Instance E
Source Zone E
Source Error E
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Source Function C
Source Instance C
Source Zone C
Source Error C
Source Function D
Source Instance D
Source Zone D
Source Error D
Source Function E
Source Instance E
Source Zone E
Source Error E
Source Value A
Source Value B
Source Value C
Source Value D
Source Value E
Output Value
Error
Source Value A
Source Value B
Source Value C
Source Value D
Source Value E
Output Value
Error
Output Function
This function configures and connects physical outputs to
internal functions.
Note:
Digital Outputs not included on these sheets
An error, when read, can indicate any of the following:
None, Open, Shorted, Measurement Error, Bad Cal Data,
Ambient Error, RTD Error, Fail, Math Error, Not Sourced,
Stale
Output
Overview
Instances - 0 to 22 per RME
Output Value
Error
Output Low
Power Scal
e
Output
Time Base
Output Control
Output High
Power Scal
e
Output Function
Output Function Instance
Output Source Zone
Output Source Error
[``o;u] Output Value : On, Off
[``Fn] Output Function : Off, Analog Input, Alarm, Cool Power,
Heat Power, Compare, Counter, Digital I/O. Profile Event Out A to
H, Function Key, Logic, Linearization, Math, Process Value,
Special Function Output 1 to 4, Timer, Variable
[`o;Ct] Output Control : Fixed Time Base, Variable Time Base
[``Fi] Output Function Instance : 1 to 250
[`o;Lo] Output Low Power Scale : 0 to 100 %
[`o;hi] Output High Power Scale : 0 to 100 %
[`o;tb] Output Time Base : 0.1 to 60.0 seconds
[``S2] Output Source Zone : 0 to 16
[otPt] Output Menu
[`SEt] Setup Page
[``Fn] Output Function : Off, Analog Input, Current, Cool Power,
Heat Power, Control Loop Power, Linearization, Math, Process
Value, Set Point Closed, Set Point Open, Special Function Outputs
1 to 4, Variable
[`s;lo] Scale Low: -100.0 to 100.0
[``Fi] Output Function Instance : 1 to 250
[`r;Lo] Range Low: -1,999.000 to 9,999.000°F
[`r;hi] Range High: -1,999.000 to 9,999.000°F
[`s;hi] Scale High: -100.0 to 100.0
[``S2] Output Source Zone : 0 to 16
[`o;Ca] Calibration Offset
[`oty] Output Type: Volts or Milliamps
Output
Off
Output
Digital
Output Low
Power Scal
e
Output
Time Base
Output Control
Output High
Power Scal
e
Output Low
Power Scal
e
Output
Time Base
Output Control
Output High
Power Scal
e
Output Function
Output Function Instance
Output Source Zone
Output Source Error
Output Function
Output Function Instance
Output Source Zone
Output Source Error
Output Value
Output Value
Error
Error
