Watlow EZ-ZONE ® RME Module • 53 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[sfn;;A]
[SFn.A] Compare (1 to 8)
Source Function A
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop
(73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed,
Control Loop (242)
[`SP;o] Set Point Open,
Control Loop (243)
[`uAr] Variable (245)
None 3980
[offset 40]
0x80 (128)
1 to 8
1
- - - - 28001 uint
RWES
[`si;A]
[ Si.A] Compare (1 to 8)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 3984
[offset 40]
0x80 (128)
1 to 8
3
- - - - 28003 uint
RWES
[`s2;A]
[ SZ.A] Compare (1 to 8)
Source Zone A
Set the zone of the function
selected above.
0 to 16 0 3988
[offset 40]
0x80 (128)
1 to 8
5
- - - - 28005 uint
RWES
[sfn;B]
[SFn.b] Compare (1 to 8)
Source Function B
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop
(73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed,
Control Loop (242)
[`SP;o] Set Point Open,
Control Loop (243)
[`uAr] Variable (245)
None 3982
[offset 40]
0x80 (128)
1 to 8
2
- - - - 28002 uint
RWES
[`si;;B]
[ Si.b] Compare (1 to 8)
Source Instance B
Set the instance of the
function selected above.
1 to 250 1 3986
[offset 40]
0x80 (128)
1 to 8
4
- - - - 28004 uint
RWES
[`s2;B]
[ SZ.b] Compare (1 to 8)
Zone Source B
Set the zone of the function
selected above.
0 to 16 0 3990
[offset 40]
0x80 (128)
1 to 8
6
- - - - 28006 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
