Watlow EZ-ZONE ® RME Module • 52 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`iP;8]
[ ip.8] Linearization (1 to 8)
Input Point 8
Set the value that will be
mapped to output 8.
-1,999.000 to 9,999.000 7.0 5568
[offset 70]
0x86 (134)
1 to 8
0x0F (15)
171 34015 float
RWES
[`oP;8]
[ op.8] Linearization (1 to 8)
Output Point 8
Set the value that will be
mapped to input 8.
-1,999.000 to 9,999.000 7.0 5588
[offset 70]
0x86 (134)
1 to 8
0x19 (25)
172 34025 float
RWES
[`iP;9]
[ ip.9] Linearization (1 to 8)
Input Point 9
Set the value that will be
mapped to output 9.
-1,999.000 to 9,999.000 8.0 5570
[offset 70]
0x86 (134)
1 to 8
0x10 (16)
173 34016 float
RWES
[`oP;9]
[ op.9] Linearization (1 to 8)
Output Point 9
Set the value that will be
mapped to input 9.
-1,999.000 to 9,999.000 8.0 5590
[offset 70]
0x86 (134)
1 to 8
0x1A (26)
174 34026 float
RWES
[iP;10]
[ip.10] Linearization (1 to 8)
Input Point 10
Set the value that will be
mapped to output 10.
-1,999.000 to 9,999.000 9.0 5572
[offset 70]
0x86 (134)
1 to 8
0x11 (17)
175 34017 float
RWES
[oP;10]
[op.10] Linearization (1 to 8)
Output Point 10
Set the value that will be
mapped to input 10.
-1,999.000 to 9,999.000 9.0 5592
[offset 70]
0x86 (134)
1 to 8
0x1B (27)
176 34027 float
RWES
[`CPE]
[`Set]
Compare Menu
[``Fn]
[ Fn] Compare (1 to 8)
Function
Set operator that will be
used to compare Source A
to Source B.
[`oFF] Off (62)
[``g;t] Greater Than
(1435)
[``L;t]
Less Than (1436)
[```E] Equal To (1437)
[``nE] Not Equal To (1438)
[`goE] Greater or Equal
(1439)
[`LoE]
Less or Equal
(1440)
Off 3996
[offset 40]
0x80 (128)
1 to 8
9
229 28009 Uint
RWES
[`toL]
[ toL] Compare (1 to 8)
Tolerance
If the difference between
Source A and Source B is
less than this value the
two will appear to be equal.
0 to 9,999.000 0.1 4000
[offset 40]
0x80 (128)
1 to 8
0x0B (11)
230 28011 float
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
