Watlow EZ-ZONE ® RME Module • 100 • Chapter 6 Features
[SFn;A] Source Function A : None, Analog Input, Current, Cool Power, Heat Power,
Power, Linearization, Math, Process Value, Set Point Closed,
Set Point Open, Variable
[SFn;C] Source Function C : None, Analog Input, Current, Cool Power, Heat Power,
Power, Linearization, Math, Process Value, Set Point Closed,
Set Point Open, Variable
[SFn;E] Source Function E : None, Alarm, Compare, Counter, Digital I/O,
Profile Event Out A to H, Function Key, Logic, Timer, Variable
[SFn;b] Source Function B : None, Analog Input, Current, Cool Power, Heat Power,
Power, Linearization, Math, Process Value, Set Point Closed,
Set Point Open, Variable
[SFn;d] Source Function D : None, Analog Input, Current, Cool Power, Heat Power,
Power, Linearization, Math, Process Value, Set Point Closed,
Set Point Open, Variable
[`S2;A] Source Zone A : 0 to 16
[`S2;C] Source Zone C : 0 to 16
[`S2;E] Source Zone E : 0 to 16
[`S2;b] Source Zone B : 0 to 16
[`S2;d] Source Zone D : 0 to 16
[`Si;A] Source Instance A : 1 to 250
[`Si;C] Source Instance C : 1 to 250
[`Si;b] Source Instance B : 1 to 250
[`S;id] Source Instance D : 1 to 250
[``Fn] Function : Off, Average, Process Scale, Deviation Scale, Switch Over,
Differential, Ratio, Add, Multiply, Absolute Difference, Minimum, Maximum,
Square Root, Sample and Hold, Pressure to Altitude, Dewpoint
[`r;Lo] Range Low : -1,999.0 to 9,999.0
[`r;hi] Range High : -1,999.0 to 9,999.0
[`S;Lo] Scale Low : -1,999.0 to 9,999.0
[`S;hi] Scale High : -1,999.0 to 9,999.0
[oFSt] Offset : -1,999.000 to 9,999.000
[P;unt] Pressure Units : PSI, Torr, mBar, Atmosphere, Pascal
[A;unt] Altitude Units : Feet, Kilofeet
[`FiL] Filter : 0.0 to 60.0 seconds
[MAt] Math Menu
[oPEr] Operation Page
[`Si;E] Source Instance E : 1 to 250
[MAt] Math Menu
[`SEt] Setup Page
[`Su;A ] Source Value A : -1,999.000 to 9,999.000
[`Su;b] Source Value B : -1,999.000 to 9,999.000
[`Su;C] Source Value C : -1,999.000 to 9,999.000
[`Su;d] Source Value D : -1,999.000 to 9,999.000
[`Su;E] Source Value E : Off, On
[``o;u] Output Value : -1,999.000 to 9,999.000
Math
Off
Range Lo
w
Range High
Pressure Units Altitude Unit
s
Scale Lo
w
Scale High
Functio
n
Filter Offset Filter
Math
Process Scale
Range Lo
w
Range High
Pressure Units Altitude Unit
s
Scale Lo
w
Scale Hig
h
Functio
n
Filter Offset Filter
Output Value = Filter [A + Offset]
Display units follows Source A
If E = OFF, Output Value = Filter [(Range High -
Range Low) / (Scale High - Scale Low) * (A - Scale
Low) + Range Low + Offset]
If B = ON, Output Value = Filter [B + Offset]
Scale Low/High and Range Low/High follows Source
A display units.
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Source Function C
Source Instance C
Source Zone C
Source Error C
Source Function D
Source Instance D
Source Zone D
Source Error D
Source Function E
Source Instance E
Source Zone E
Source Error E
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Source Function C
Source Instance C
Source Zone C
Source Error C
Source Function D
Source Instance D
Source Zone D
Source Error D
Source Function E
Source Instance E
Source Zone E
Source Error E
Source Value A
Source Value B
Source Value C
Source Value D
Source Value E
Output Value
Error
Source Value A
Source Value B
Source Value C
Source Value D
Source Value E
Output Value
Error
