Watlow EZ-ZONE ® RME Module • 47 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`S;hi]
[ S.hi] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Scale High **
Set the scale high for pro-
cess output in electrical
units. This value, in volts
or milliamps, will corre-
spond to 100% PID power
output or range high value.
-100.0 to 100.0 10.00 7008
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
0xA (10)
- - - - 18010 float
RWES
[`r;Lo]
[ r.Lo] Output Process(1 to 3, 7 to
9, 13 to 15, 19 to 21)
Range Low **
Use to set the minimum
value in process units. This
will correspond with the
Scale Low value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18°C
7010
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
0xB (11)
- - - - 18011 float
RWES
[`r;hi]
[ r.hi] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Range High **
Use to set the maximum
value in process units. This
will correspond with the
Scale High value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
100F or
units
38C
7012
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
0xC (12)
- - - - 18012 float
RWES
[`o;CA]
[ o.CA] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Calibration Offset **
Set an offset value for a
process output.
-1,999.000 to 9,999.000°F
or units
-1,110.555 to 5,555.000°C
0.0°F or
units
0.0°C
7002
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
7
- - - - 18007 float
RWES
[Alm]
[`Set]
Alarm Menu
[`A;ty]
[ A.ty] Alarm (1 to 8)
Type
Select whether the alarm
trigger is a fixed value or
will track the set point.
[`oFF] Off (62)
[PR;AL] Process Alarm (76)
Off 1468
[offset 60]
0x6D (109)
1 to 8
0x0F (15)
2 9015 uint
RWES
[SFn;A]
[SFn.A] Alarm (1 to 8)
Source
Select what will trigger
this alarm.
[none] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[PWr] Power, Control Loop
(73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`uAr] Variable (245)
[`Cu;r] Current Read (179)
1472
[offset 60]
0x6D (109)
1 to 8
0x11 (17)
3 9017 uint
RWES
[`si;A]
[ Si.A] Alarm (1 to 8)
Source Instance
Set the instance of the
function selected above.
1 or 250 1 1474
[offset 60]
0x6D (109)
1 to 8
0x12 (18)
4 9018 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
