Watlow EZ-ZONE
®
RME Module
•
74
•
Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`on;t]
[ on.t]
Special Output (1 to 4)
On Time
If Function is set to Com-
pressor Control:
• Set Minimum On Time
and Minimum Off Time
to the minimum span
of time, in seconds, that
the compressor will be
on or off.
0 to 9,999 seconds
20
6662
[offset 80]
0x87 (135)
1 to 4
0x16 (22)
190
35022
uint
RWES
[`oF;t]
[ oF.t]
Special Output (1 to 4)
Off Time
0 to 9,999 seconds
20
6664
[offset 80]
0x87 (135)
1 to 4
0x17 (23)
191
35023
uint
RWES
[`t;t]
[ t.t]
Special Output (1 to 8)
Valve Travel Time
If Function is set to Motor-
ized Valve:
Source A will determine
the valve position.
• Set this time in seconds
representing the time
that it will take the
valve to travel between
fully closed and fully
open.
10 to 9,999 seconds
120
6666
[offset 80]
0x87 (135)
1 to 4
0x18 (24)
192
35024
uint
RWES
[``db]
[ db]
Special Output (1 to 4)
Dead Band
If Function is set to Motor-
ized Valve:
• Set to the minimum
valve adjustment as a
percentage, represent-
ing the movement of the
valve in a single action.
A small value improves
accuracy and depletes
valve life where a large
value reduces the num-
ber of adjustments (less
accurate)and the wear
on the mechanism.
1.0 to 100.0%
2
6668
[offset 80]
0x87 (135)
1 to 4
0x19 (25)
193
35025
float
RWES
[`o;S1]
[ o.S1]
Special Output (1 to 4)
Output 1 Size
If Function is set to Se-
quencer:
• Set Output 1 Size, as a
percentage of the total
capacity of all output
devices, or vernier out-
put. This value must
be larger than the
values set for outputs 2
through 4.
0 to 9,999
10
6674
[offset 80]
0x87 (135)
1 to 4
0x1C (28)
- - - -
35028
float
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
