Watlow EZ-ZONE ® RME Module • 76 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`uAr]
[`Set]
Variable Menu
[tyPE]
[tyPE] Variable 1 to 8
Data Type
Set the variable's data
type.
[AnLg] Analog (1215)
[`Dig] Digital (1220)
Analog 6380
[offset 20]
0x66 (102)
1 to 8
1
210 2001 uint
RWES
[Unit]
[Unit] Variable 1 to 8
Units
Set the variable's units.
Note:
Units are always in de-
grees F when used for
temperature
[nonE] None (61)
[`r;tp] Relative Tempera-
ture (1541)
[`A;tp] Absolute Tempera-
ture (1540)
[``rh] Relative Humidity
(1538)
[PWr] Power (73)
[`Pro] Process (75)
Absolute
Temper-
ature
6392
[offset 20]
0x66 (102)
1 to 8
7
- - - - 2007 uint
RWES
[`Dig]
[ Dig] Variable 1 to 8
Digital
Set the variable's value.
[`oFF] Off (62)
[``on] On (63)
Off 6382
[offset 20]
0x66 (102)
1 to 8
2
211 2002 uint
RWES
[anLg]
[AnLg] Variable 1 to 8
Analog
Set the variable's value.
-1,999.000 to 9,999.000 0.0 6384
[offset 20]
0x66 (102)
1 to 8
3
212 2003 float
RWES
[gLbL]
[`Set]
Global Menu
[`C_F]
[ C_F] Global
Display Units
Select which scale to use
for temperature.
[```F] °F (30)
[```C] °C (15)
°F 6948 0x67 (103)
1
5
110 3005 uuint
RWES
[AC;LF]
[AC.LF] Global
AC Line Frequency
Set the frequency to the
applied ac line power
source.
[``50] 50 Hz (3)
[``60] 60 Hz (4)
60 Hz 366 0x6A (106)
1
4
- - - - 6004 uint
RWES
[d;prs]
[dPrS] Global
Display Pairs
Defines the number of Dis-
play Pairs.
1 to 10 1 - - - - 0x67 (103)
1
0x1C (28)
- - - - 3028 uuint
RWES
[USr;S]
[USr.S] Global
User Settings Save
Save all of this controller's
settings to the selected set
that have a Data Type of
RWES
[SEt1] User Set 1 (101)
[none] None (61)
None 26 0x65
(101)
1
0x0E (14)
118 1014 uuint
RWE
[USr;r]
[USr.r] Global
User Settings Restore
Replace all of this control-
ler's settings with another
set.
[FCty] Factory (31)
[none] None (61)
[SEt1] User Set 1 (101)
None 24 0x65
(101)
1
0x0D (13)
117 1013 uuint
RWE
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
