Watlow EZ-ZONE ® RME Module • 8 • Chapter 1 Overview
A Conceptual View of RM Hardware Configurations
Due to the scalability and flexibility in the system
components a user has several options available in
the way that the hardware can be connected. Listed
below are a few examples.
RM System Connected to a Remote User Interface
(RUI) and a PC
In this configuration the RUI and PC are connected
to the RM system via Watlow's Standard Bus where
both will be able to talk directly to any interconnect-
ed system module.
RM
Control
RM
Expansion
RUI
PC
EZ-ZONE
Configurator
Power
Supply
Slot C Slot C
The PC running EZ-ZONE Configurator software
and the RUI can be used to configure and then moni-
tor both modules.
RM System Connected to a Programmable Log-
ic Controller (PLC) on a DIN Rail
In this configuration the PLC can be connected to
the RM system via the Access module using one or
more available protocols:
1. EtherNet/IP and or Modbus TCP
2. DeviceNet
3. Modbus RTU
4. Profibus DP
RM
Control
RM
Access
RM
Expansion
PLC
Power
Supply
Slot C Slot C Slot C
Slot E
RM System Connected to an Operator Interface
Terminal (OIT) through an RUI/Gateway
In this configuration the HMI can be running any
of a number of protocols communicating to the RM
system through Watlow's RUI/Gateway. Available
protocols for the RUI/Gateway follow:
1. EtherNet/IP and or Modbus TCP
2. DeviceNet
3. Modbus RTU
4. Profibus DP
RM
Control
RM
Expansion
OIT
Slot C Slot C
RUI/Gateway
Power
Supply
RM System Connected to a Split Rail with OIT
In this configuration both the Inter-module Bus
(backplane communications) and Standard Bus are
connected between rails to allow for remote capabili-
ties. It is recommended that the split rail connection
not exceed 200 feet. In this configuration the OIT
can communicate with all modules (maximum 16
modules any combination with one Access module).
RM
Control
RM
Access
RM
Expansion
OIT
RM
Control
RM
Expansion
RM
Expansion
Slot E
Slot C
Slot C Slot C Slot C
Slot C Slot C
Power
Supply
