Watlow EZ-ZONE ® RME Module • 34 • Chapter 3 Operations Page
RME Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
No Dis-
play
Compare (1 to 8)
Error
Read reported cause for
compare error
None (61)
Open (65)
Shorted (127)
Measurement error (140)
Bad Cal Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617) - - - - 4004
[offset 40] 0x80
(128)
1 to 8
0x0D (13)
- - - - 28013 uint
R
[tMr]
[oPEr]
Timer Menu
[`Su;A]
[ Su.A] Timer (1 to 8)
Source Value A
View the value of Source
A.
[`off] Off (62)
[``on] On (63)
- - - - 4952
[off 50] 0x83
(131)
1 to 8
7
- - - - 31007 uint
R
[`Su;b]
[ Su.b] Timer (1 to 8)
Source Value B
View the value of Source
B.
[`off] Off (62)
[``on] On (63)
- - - - 4954
[off 50] 0x83
(131)
1 to 8
8
- - - - 31008 uint
R
[``E;t]
[ E.t] Timer (1 to 8)
Elapsed Time
View the value of this
function's elapsed time.
0.0 to 30,000.000 seconds - - - - 4970
[off 50] 0x83
(131)
1 to 8
0x10 (16)
- - - - 31016 float
R
[``o;u]
[ o.v] Timer (1 to 8)
Output Value
View the value of this
function's output.
[`off] Off (62)
[``on] On (63)
- - - - 4958
[off 50] 0x83
(131)
1 to 8
0xA (10)
- - - - 31010 uint
R
No Dis-
play
Timer (1 to 8)
Error
Read reported cause for
timer error
None (61)
Open (65)
Shorted (127)
Measurement error (140)
Bad Cal Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617) - - - - 4974
[offset 50] 0x83
(131)
1 to 8
0x12 (18)
- - - - 31018 uint
R
[`Ctr]
[oPEr]
Counter Menu
[`Cnt]
[ Cnt] Counter (1 to 8)
Count
View the function's total
count.
0 to 9,999 - - - - 4488
[off 40] 0x82
(130)
1 to 8
0xF (15)
143 30015 uint
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EE-
PROM
S: User
Set
