Watlow EZ-ZONE ® RME Module
•
113
•
Chapter 7 Appendix
Indication Description Possible Cause(s) Corrective Action
No Serial Communi-
cation
Cannot establish serial com-
munications with the con-
troller
• Address parameter incorrect
• Incorrect protocol selected
• Baud rate incorrect
• Parity incorrect
• Wiring error
• EIA-485 converter issue
• Incorrect computer or PLC communi-
cations port
• Incorrect software setup
• Wires routed with power cables
• Termination resistor may be required
• Set unique addresses on network
• Match protocol between devices
• Match baud rate between devices
• Match parity between devices
• Correct wiring issue
• Check settings or replace converter
• Set correct communication port
• Correct software setup to match con-
troller
• Route communications wires away
from power wires
• Place 120 Ω resistor across EIA-485
on last controller
Device Error
[`100]
[rEtn]
Controller displays internal
malfunction message at
power up.
• Controller defective
• Sensor input over driven
• Replace or repair controller
• Check sensors for ground loops, re-
verse wiring or out of range values.
Heater Error
[`h;Er] Heater Error • Current through load is above current
trip set point
• Check that the load current is proper.
Correct cause of overcurrent and/or en-
sure current trip set point is correct.
• Current through load is below current
trip set point
• Check that the load current is proper.
Correct cause of undercurrent and/or
ensure current trip set point is correct.
Current Error
[`C;Er] Load current incorrect. • Shorted solid-state or mechanical
relay
• Replace relay
• Open solid-state or mechanical relay • Replace relay
• Current transformer load wire associ-
ated to wrong output
• Route load wire through current
transformer from correct output, and
go to the [`C;Si] Source Output In-
stance parameter (Setup Page, Current
Menu) to select the output that is driv-
ing the load.
• Defective current transformer or con-
troller
• Replace or repair sensor or controller
• Noisy electrical lines • Route wires appropriately, check for
loose connections, add line filters
Remote User Inter-
face (RUI) menus
inaccessible
Unable to access [`SEt],
[OPEr] , [FCty] or [ProF]
menus or particular prompts
in Home Page
• Security set to incorrect level • Check [`loC] settings in Factory Page
• Enter appropriate password in [UloC]
setting in Factory Page
• Digital input set to lockout keypad • Change state of digital input
• Custom parameters incorrect • Change custom parameters in Factory
Page
RUI value to low
[ual;l] Value to low to be displayed
in 4 digit LED display
<-1999
• Incorrect setup • Check scaling of source data
RUI value to high
[ual;h] Value to high to be displayed
in 4 digit LED display
>9999
• Incorrect setup • Check scaling of source data
