Action menu – Watlow EZ-ZONE RME User Manual
Page 45
Watlow EZ-ZONE
®
RME Module
•
42
•
Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[``Fi]
[ Fi]
Digital Output (1 to 24)
Function Instance
Set the instance of the
function selected above.
1 to 24
1
370
[offset 30]
0x6A (106)
1 to (24)
6
84
6006
uint
RWES
[``s2]
[ SZ]
Digital Output (1 to 24)
Source Zone
Set the zone of the function
selected above.
0 to 16
0
382
[offset 30]
0x6A (106)
1 to (24)
0xC (12)
- - - -
6012
uint
RWES
[`o;Ct]
[ o.Ct]
Digital Output (1 to 24)
Control
Set the output control type.
This parameter is only
used with PID control, but
can be set anytime.
[`Ftb]
Fixed Time Base
(34)
[`utb]
Variable Time Base
(103)
Fixed
Time
Base
362
[offset 30]
0x6A (106)
1 to (24)
2
85
6002
uint
RWES
[`o;tb]
[ o.tb]
Digital Output (1 to 24)
Time Base
Set the time base for fixed-
time-base control.
[ 0.1 for Fast and Bi-Di-
rectional outputs, 5.0 for
Slow outputs] to 60
364
[offset 30]
0x6A (106)
1 to (24)
3
86
6003
float
RWES
[`o;Lo]
[ o.Lo]
Digital Output (1 to 24)
Low Power Scale
The power output will nev-
er be less than the value
specified and will represent
the value at which output
scaling begins.
0.0 to 100.0
0.0
376
[offset 30]
0x6A (106)
1 to (24)
9
87
6009
float
RWES
[`o;hi]
[ o.hi]
Digital Output (1 to 24)
High Power Scale
The power output will
never be greater than the
value specified and will
represent the value at
which output scaling stops.
0.0 to 100.0
100.0
378
[offset 30]
0x6A (106)
1 to (24)
0xA (10)
88
6010
float
RWES
[`ACt]
[`SEt]
Action Menu
[``Fn]
[ Fn]
Action (1 to 8)
Function
Set the action that will be
triggered by this function.
[nonE]
None (61)
[USr;r]
User Settings Re-
store (227)
[ALM]
Alarm (6)
[`SiL]
Silence Alarms
(108)
[`AoF]
Control Loops Off
and Alarms to Non-alarm
State (220)
[`F;AL]
Force Alarm to Oc-
cur (218)
None
1284
[offset 20]
0x6E (110)
1 to 8
3
138
10003
uint
RWES
[``Fi]
[ Fi]
Action (1 to 8)
Function Instance
Set the instance of the
function selected above.
0 to 24
0
1286
[offset 20]
0x6E (110)
1 to 8
4
139
10004
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
