ZyWALL 5 User’s Guide
Chapter 3 Wizard Setup
77
Starting IP
Address
When the Local Network field is configured to Single, enter a (static) IP address on
the LAN behind your ZyWALL. When the Local Network field is configured to Range
IP, enter the beginning (static) IP address, in a range of computers on the LAN behind
your ZyWALL. When the Local Network field is configured to Subnet, this is a (static)
IP address on the LAN behind your ZyWALL.
Ending IP
Address/
Subnet Mask
When the Local Network field is configured to Single, this field is N/A. When the
Local Network field is configured to Range IP, enter the end (static) IP address, in a
range of computers on the LAN behind your ZyWALL. When the Local Network field
is configured to Subnet, this is a subnet mask on the LAN behind your ZyWALL.
Remote
Network
Remote IP addresses must be static and correspond to the remote IPSec router's
configured local IP addresses.
Select Single for a single IP address. Select Range IP for a specific range of IP
addresses. Select Subnet to specify IP addresses on a network by their subnet mask.
Starting IP
Address
When the Remote Network field is configured to Single, enter a (static) IP address
on the network behind the remote IPSec router. When the Remote Network field is
configured to Range IP, enter the beginning (static) IP address, in a range of
computers on the network behind the remote IPSec router. When the Remote
Network field is configured to Subnet, enter a (static) IP address on the network
behind the remote IPSec router
Ending IP
Address/
Subnet Mask
When the Remote Network field is configured to Single, this field is N/A. When the
Remote Network field is configured to Range IP, enter the end (static) IP address, in
a range of computers on the network behind the remote IPSec router. When the
Remote Network field is configured to Subnet, enter a subnet mask on the network
behind the remote IPSec router.
Back
Click Back to return to the previous screen.
Next
Click Next to continue.
Table 13 VPN Wizard : Network Setting
LABEL
DESCRIPTION
