ZyWALL 5 User’s Guide

458

Chapter 33 Network Address Translation (NAT)

Figure 271 Example 3: Final Menu 15.1.1

Now configure the IGA3 to map to our web server and mail server on the LAN.

1 Enter 15 from the main menu.

2 Enter 2 to go to Menu 15.2 - NAT Server Sets and configure it as shown in

Figure 272

.

Menu 15.1.1 - Address Mapping Rules

Set Name= Example3

Idx Local Start IP Local End IP Global Start IP Global End IP
Type
--- --------------- -------------- --------------- --------------- -
--
1. 192.168.1.10 10.132.50.1 1-1
2 192.168.1.11 10.132.50.2 1-1
3. 0.0.0.0 255.255.255.255 10.132.50.3 M-1
4. 10.132.50.3
Server
5.
6.
7.
8.
9.
10.

Action= Edit Select Rule=

Press ENTER to Confirm or ESC to Cancel:
