ZyWALL 5 User’s Guide

418

Chapter 28 LAN Setup

Figure 230 Menu 3.1: LAN Port Filter Setup

28.4 TCP/IP and DHCP Ethernet Setup Menu

From the main menu, enter 3 to open Menu 3 - LAN Setup to configure TCP/IP (RFC 1155)
and DHCP Ethernet setup.

Figure 231 Menu 3: TCP/IP and DHCP Setup

From menu 3, select the submenu option TCP/IP and DHCP Setup and press [ENTER]. The
screen now displays

Menu 3.2 - TCP/IP and DHCP Ethernet Setup

,

as shown next.

Menu 3.1 - LAN Port Filter Setup

Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=

Press ENTER to Confirm or ESC to Cancel:

Menu 3 - LAN Setup

1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup

5. Wireless LAN Setup

Enter Menu Selection Number:
