ZyXEL Communications ZyXEL ZyWALL 5 - Manual (Page 171)

ZyWALL 5 User’s Guide
170 Chapter 10 Firewall Screens
Figure 65 Default Rule (Router Mode)
The following table describes the labels in this screen.
Table 48 Default Rule (Router Mode)
LABEL DESCRIPTION
Enable Firewall Select this check box to activate the firewall. The ZyWALL performs access control
and protects against Denial of Service (DoS) attacks when the firewall is activated.
Allow
Asymmetrical
Route
Select this check box to have the ZyWALL firewall permit the use of triangle route
topology on the network.
Note: Allowing asymmetrical routes may let traffic from the WAN go
directly to a LAN computer without passing through the
ZyWALL. See the appendices for more on triangle route
topology and how to deal with this problem.
Packet Direction This is the direction of travel of packets (LAN to LAN/ZyWALL, LAN to WAN, LAN
to DMZ, WAN to LAN, WAN to WAN/ZyWALL, WAN to DMZ, DMZ to LAN, DMZ
to WAN or DMZ to DMZ/ZyWALL).
Firewall rules are grouped based on the direction of travel of packets to which they
apply. For example, LAN to LAN/ZyWALL means packets traveling from a
computer/subnet on the LAN to either another computer/subnet on the LAN interface
of the ZyWALL or the ZyWALL itself.
Default Action Use the drop-down list boxes to select whether to Block (silently discard) or
Forward (allow the passage of) packets that are traveling in the selected direction.
Log Select the check box to create a log (when the above action is taken) for packets
that are traveling in the selected direction and do not match any of the rules below.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
