ZyWALL 5 User’s Guide
242 Chapter 14 VPN Screens
Figure 111 VPN Rules (IKE): Network Policy Move
The following table describes the labels in this screen.
14.13 Manual VPN Rule Summary Screen
Refer to Figure 107 on page 230 for a graphical representation of the fields in the web
configurator.
Click VPN and the VPN Rules (Manual) tab to open the VPN Rules screen. This is a read-
only menu of your IPSec rules (tunnels). Edit an IPSec rule by clicking the edit icon to
configure the associated submenus.
Table 70 VPN Rules (IKE): Network Policy Move
LABEL DESCRIPTION
Network Policy
Information
The following fields display the general network settings of this VPN policy.
Name This field displays the policy name.
Local Network This field displays one or a range of IP address(es) of the computer(s) behind the
ZyWALL.
Remote Network This field displays one or a range of IP address(es) of the remote network behind
the remote IPsec router.
Gateway Policy
Information
Gateway Policy Select the name of a VPN rule (or gateway policy) to which you want to associate
this VPN network policy.
If you do not want to associate a network policy to any gateway policy, select
Recycle Bin from the drop-down list box. The Recycle Bin gateway policy is a
virtual placeholder for any network policy(ies) without an associated gateway
policy. When there is a network policy in Recycle Bin, the Recycle Bin gateway
policy automatically displays in the VPN Rules (IKE) screen.
Apply Click Apply to save the changes.
Cancel Click Cancel to discard all changes and return to the main VPN screen.
