ZyWALL 5 User’s Guide
482 Chapter 37 System Information & Diagnosis
3 There are three commands in Menu 24.1 - System Maintenance - Status. Entering 1
drops the WAN connection, 9 resets the counters and [ESC] takes you back to the
previous screen.
Figure 295 Menu 24.1: System Maintenance: Status
The following table describes the fields present in Menu 24.1 - System Maintenance -
Status. These fields are READ-ONLY and meant for diagnostic purposes. The upper right
corner of the screen shows the time and date according to the format you set in menu 24.10.
Menu 24.1 - System Maintenance - Status 06:23:52
Mon. Mar. 07, 2005
Port Status TxPkts RxPkts Cols Tx B/s Rx B/s Up Time
WAN 100M/Full 126 227 0 0 0 0:02:45
LAN 100M/Full 168 427 0 312 382 0:02:46
WLAN Down 0 0 0 0 0 0:00:00
DMZ 100M/Full 6 0 0 0 0 0:02:46
Port Ethernet Address IP Address IP Mask DHCP
WAN 00:A0:C5:7A:86:D6 172.23.19.106 255.255.255.0 Client
LAN 00:A0:C5:7A:86:D5 192.168.1.1 255.255.255.0 Server
WLAN 00:00:00:00:00:00
DMZ 00:A0:C5:7A:86:D7 0.0.0.0 0.0.0.0 None
System up Time: 0:02:51
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
Table 186 System Maintenance: Status Menu Fields
FIELD DESCRIPTION
Port This field identifies a port (WAN, LAN, WLAN or DMZ) on the ZyWALL.
Status This field shows the port speed and duplex setting if you’re using Ethernet
Encapsulation and Down (line is down), Idle (line (ppp) idle), Dial (starting to
trigger a call) or Drop (dropping a call) if you’re using PPPoE Encapsulation.
TxPkts This is the number of transmitted packets on this port.
RxPkts This is the number of received packets on this port.
Cols This is the number of collisions on this port.
Tx B/s This field shows the transmission speed in Bytes per second on this port.
Rx B/s This field shows the reception speed in Bytes per second on this port.
Up Time This is the total amount of time the line has been up.
Ethernet Address This is the Ethernet address of the port listed on the left.
IP Address This is the IP address of the port listed on the left.
IP Mask This is the IP mask of the port listed on the left.
DHCP This is the DHCP setting of the port listed on the left.
