ZyWALL 5 User’s Guide
654
Appendix Q Log Descriptions
Syslog Logs
There are two types of syslog: event logs and traffic logs. The device generates an event log
when a system event occurs, for example, when a user logs in or the device is under attack.
The device generates a traffic log when a "session" is terminated. A traffic log summarizes the
session's type, when it started and stopped the amount of traffic that was sent and received and
so on. An external log analyzer can reconstruct and analyze the traffic flowing through the
device after collecting the traffic logs.
The following table shows RFC-2408 ISAKMP payload types that the log displays. Please
refer to the RFC for detailed information on each type.
0
Timestamp reply message
15
Information Request
0
Information request message
16
Information Reply
0
Information reply message
Table 54 Syslog Logs
LOG MESSAGE
DESCRIPTION
Event Log:
hr:mm:ss hostname
src="
dst="
note="
cat="
This message is sent by the system ("RAS" displays as the
system name if you haven’t configured one) when the router
generates a syslog. The facility is defined in the Log
Settings screen. The severity is the log’s syslog class. The
definition of messages and notes are defined in the various
log charts throughout this appendix. The “devID” is the MAC
address of the router’s LAN port. The “cat” is the same as
the category in the router’s logs.
Traffic Log:
dd hr:mm:ss hostname
src="
dst="
note="Traffic Log" devID="
duration=seconds sent=sentBytes
rcvd=receiveBytes dir="
protoID=IPProtocolID
proto="serviceName" trans="IPSec/
Normal"
This message is sent by the device when the connection
(session) is closed. The facility is defined in the Log
Settings screen. The severity is the traffic log type. The
message and note always display "Traffic Log". The "proto"
field lists the service name. The "dir" field lists the incoming
and outgoing interfaces ("LAN:LAN", "LAN:WAN",
"LAN:DMZ", "LAN:DEV" for example).
Table 55 RFC-2408 ISAKMP Payload Types
LOG DISPLAY
PAYLOAD TYPE
SA
Security Association
PROP
Proposal
TRANS
Transform
Table 53 ICMP Notes (continued)
TYPE
CODE
DESCRIPTION
