ZyWALL 5 User’s Guide
498 Chapter 38 Firmware and Configuration File Maintenance
38.3.8 GUI-based TFTP Clients
The following table describes some of the fields that you may see in GUI-based TFTP clients.
Refer to Section 38.3.5 on page 496 to read about configurations that disallow TFTP and FTP
over WAN.
38.3.9 Backup Via Console Port
Back up configuration via console port by following the HyperTerminal procedure shown
next. Procedures using other serial communications programs should be similar.
1 Display menu 24.5 and enter “y” at the following screen.
Figure 307 System Maintenance: Backup Configuration
2 The following screen indicates that the Xmodem download has started.
Figure 308 System Maintenance: Starting Xmodem Download Screen
3 Run the HyperTerminal program by clicking Transfer, then Receive File as shown in the
following screen.
Table 192 General Commands for GUI-based TFTP Clients
COMMAND DESCRIPTION
Host Enter the IP address of the ZyWALL. 192.168.1.1 is the ZyWALL’s default IP
address when shipped.
Send/Fetch Use “Send” to upload the file to the ZyWALL and “Fetch” to back up the file on your
computer.
Local File Enter the path and name of the firmware file (*.bin extension) or configuration file
(*.rom extension) on your computer.
Remote File This is the filename on the ZyWALL. The filename for the firmware is “ras” and for
the configuration file, is “rom-0”.
Binary Transfer the file in binary mode.
Abort Stop transfer of the file.
Ready to backup Configuration via Xmodem.
Do you want to continue (y/n):
You can enter ctrl-x to terminate operation any
time.
Starting XMODEM download...
