ZyWALL 5 User’s Guide
430
Chapter 30 DMZ Setup
30.3.1 IP Address
From the main menu, enter 5 to open Menu 5 - DMZ Setup to configure TCP/IP (RFC 1155).
Figure 241 Menu 5: TCP/IP Setup
From menu 5, select the submenu option 2. TCP/IP Setup and press [ENTER]. The screen
now displays
Menu 5.2 - TCP/IP Setup
,
as shown next.
Figure 242 Menu 5.2: TCP/IP Setup
The TCP/IP setup fields are the same as the ones in Menu 3.2 - TCP/IP Ethernet Setup.
Each public server will need a unique IP address. Refer to
information on how to configure these fields.
Note: DMZ and LAN IP addresses must be on separate subnets. You must also
configure NAT for the DMZ port (see
) in menus 15.1
and 15.2.
30.3.2 IP Alias Setup
You must use menu 5.2 to configure the first network. Move the cursor to the Edit IP Alias
field, press [SPACE BAR] to choose Yes and press [ENTER] to configure the second and
third network.
Pressing [ENTER] opens Menu 5.2.1 - IP Alias Setup, as shown next.
Menu 5 - DMZ Setup
1. DMZ Port Filter Setup
2. TCP/IP Setup
Enter Menu Selection Number:
Menu 5.2 - TCP/IP Ethernet Setup
TCP/IP Setup:
IP Address= 0.0.0.0
IP Subnet Mask= 0.0.0.0
RIP Direction= Both
Version= RIP-1
Multicast= None
Edit IP Alias= No
Press ENTER to Confirm or ESC to Cancel:
