ZyWALL 5 User’s Guide
54
Chapter 1 Getting to Know Your ZyWALL
SYS
Green
Off
The ZyWALL is not ready or has failed.
On
The ZyWALL is ready and running.
Flashing
The ZyWALL is restarting.
ACT
Green
Off
The backup port is not connected.
Flashing
The backup port is sending or receiving packets.
CARD
Green
Off
The wireless LAN is not ready, or has failed.
On
The wireless LAN is ready.
Flashing
The wireless LAN is sending or receiving packets.
WAN 10/100
Off
The WAN connection is not ready, or has failed.
Green
On
The ZyWALL has a successful 10Mbps WAN connection.
Flashing
The 10M WAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps WAN connection.
Flashing
The 100M WAN is sending or receiving packets.
LAN/DMZ
10/100
Off
The LAN/DMZ is not connected.
Green
On
The ZyWALL has a successful 10Mbps Ethernet connection.
Flashing
The 10M LAN is sending or receiving packets.
Orange
On
The ZyWALL has a successful 100Mbps Ethernet connection.
Flashing
The 100M LAN is sending or receiving packets.
Table 1 Front Panel LEDs (continued)
LED
COLOR
STATUS
DESCRIPTION
