ZyWALL 5 User’s Guide
172 Chapter 10 Firewall Screens
10.6.1 Rule Summary
Note: The ordering of your rules is very important as rules are applied in turn.
Click FIREWALL, then the Rule Summary tab to open the screen.
Figure 67 Rule Summary
The following table describes the labels in this screen.
Apply Click Apply to save your changes back to the ZyWALL.
Reset Click Reset to begin configuring this screen afresh.
Table 49 Default Rule (Bridge Mode)
LABEL DESCRIPTION
Table 50 Rule Summary
LABEL DESCRIPTION
Firewall Rules
Storage Space
in Use
This bar displays the percentage of the ZyWALL’s firewall rules storage space that is
currently in use. The bar turns from green to red when the maximum is being
approached. When the bar is red, you should consider deleting unnecessary firewall
rules before adding more firewall rules.
Packet Direction Use the drop-down list box to select a direction of travel of packets (LAN to LAN/
ZyWALL, LAN to WAN, LAN to DMZ, WAN to WAN/ZyWALL, WAN to LAN, WAN
to DMZ, DMZ to DMZ/ZyWALL, DMZ to LAN or DMZ to WAN) for which you want
to configure firewall rules.
Default Policy This field displays the default action and log policy you selected in the Default Rule
screen for the packet direction shown in the field above.
The following read-only fields summarize the rules you have created that apply to traffic traveling in the
selected packet direction. The firewall rules that you configure (summarized below) take priority over
the general firewall action settings above.
