ZyWALL 5 User’s Guide
Chapter 33 Network Address Translation (NAT)
447
The following table describes the fields in this menu.
33.2 NAT Setup
Use the address mapping sets menus and submenus to create the mapping table used to assign
global addresses to computers on the LAN and the DMZ. Set 255 is used for SUA. When you
select Full Feature in menu 4 or menu 11.1.2, the SMT will use Set 1. When you select SUA
Only, the SMT will use the pre-configured Set 255 (read only).
The server set is a list of LAN and DMZ servers mapped to external ports. To use this set, a
server rule must be set up inside the NAT address mapping set. Please see the section on port
forwarding in
for further information on these menus. To configure
NAT, enter 15 from the main menu to bring up the following screen.
Figure 256 Menu 15: NAT Setup
Note: Configure DMZ and LAN IP addresses in NAT menus 15.1 and 15.2. DMZ IP
addresses must be on subnets separate from LAN IP addresses.
33.2.1 Address Mapping Sets
Enter 1 to bring up Menu 15.1 - Address Mapping Sets.
Table 174 Applying NAT in Menus 4 & 11.1.2
FIELD
DESCRIPTION
OPTIONS
Network
Address
Translation
When you select this option the SMT will use Address Mapping Set 1
(menu 15.1 - see
for further discussion). You
can configure any of the mapping types described in
Choose Full Feature if you have multiple public WAN IP addresses for
your ZyWALL.
When you select Full Feature you must configure at least one address
mapping set.
Full Feature
NAT is disabled when you select this option.
None
When you select this option the SMT will use Address Mapping Set 255
(menu 15.1 - see
). Choose SUA Only if you
have just one public WAN IP address for your ZyWALL.
SUA Only
Menu 15 - NAT Setup
1. Address Mapping Sets
2. Port Forwarding Setup
3. Trigger Port Setup
Enter Menu Selection Number:
