Text mode
Original mode

the Adjust Separator Length [Y/N] prompt does not affect
the length of the separator tag.

A d j u s t i n g t h e C u t P o s i t i o n

This feature adjusts where the tag is cut. The printer adjusts the
cut position according to the black sensor marks on the supply.

◆

You may need to adjust the cut up or down for aperture
supplies.

◆

If the cut occurs in the preprint of the supply, move the cut up.

The default is increase (I) from step zero (0). The steps are in
1/192 inches (one dot). A dot is the smallest area on which the
printer can print. Increase moves the cut up; decrease moves the
cut down.

1. From the main menu select Printer Options and

press e .

2. When you see

Select Printer Option:
Use Batch Separators

press d to display Adjust Cut Position, then
press e .

Setting Printer Options 5-3
