3. Mark the start location (horizontal/vertical) of each field. The
illustration below shows which coordinates to use for each
field rotation.
If the field rotation is
Use the coordinates for the
Top
Left
Bottom
Right
Lower left corner of the field
Lower right corner of the field
Upper right corner of the field
Upper left corner of the field
The following layout shows the start location
(horizontal/vertical point) for each field.
7-16 Entering a Format
