Cleaning
277
9
Cleaning the Copy Paper
Transport Mechanism
Main Paper Tray
AAAA
Open the side cover of the main
paper tray.
Note
❒ You cannot open the paper tray
side cover when the optional
Bypass Tray Unit is installed.
Remove the optional Bypass
Tray Unit first, and then open
the paper tray side cover. See
p.278 “Optional Bypass Tray
Unit”.
BBBB
Wipe the two rollers with a soft
cloth that has been dampened
with water and wrung out.
1.
Roller
CCCC
Close the side cover of the main
paper tray, making sure that it
locks firmly into place.
Optional Paper Tray Unit
AAAA
Open the side cover of the Paper
Tray Unit.
BBBB
Wipe the five rollers with a soft
cloth that has been dampened
with water and wrung out.
1.
Roller
CCCC
Close the unit's side cover mak-
ing sure it locks firmly into place.
