System Board

Assigned Device Interrupts

Chapter 2

61

Although you can use the Setup program to change some of the settings, the following
address map isn’t completely BIOS dependent but is determined partly by the operating
system. Note that some of the interrupts are allocated dynamically.

Three major interrupt modes are available:

PIC mode: This mode uses only legacy interrupt controllers, so only one processor
can be supported. Because this system has dual-processor capability, Windows NT
doesn’t choose this mode as the default. However, during Windows NT installation,
you can select this mode.

Virtual wire mode: This mode is implemented with APIC controllers in the ICH2
and P64H and used during boot time. The virtual wire mode allows the transition to
the symmetric I/O mode. In the virtual wire mode, only one processor executes
instructions.

Symmetric I/O mode: This mode is implemented with APIC controllers in the
ICH2 and P64H and allows for multiple processor operations.

NOTE

In PIC mode and virtual wire mode, PCI interrupts are routed to the INT line. In
symmetric I/O mode, PCI interrupts are routed to the I/O APIC controllers and
forwarded over an APIC bus to the processors.

Interrupt Source

APIC Controller

Interrupt Signalling on

of device

Input

(PIC

mode)

a

(APIC

modes)

INTA - PCI slot 3 (32/33)

P64H

IRQ0

BT_INT

APIC bus

INTB - PCI slot 3 (32/33)

P64H

IRQ1

BT_INT

APIC bus

INTC - PCI slot 3 (32/33)

P64H

IRQ2

BT_INT

APIC bus

INTD - PCI slot 3 (32/33)

P64H

IRQ3

BT_INT

APIC bus

INTA - PCI slot 4 (32/33)

P64H

IRQ4

BT_INT

APIC bus

INTB - PCI slot 4 (32/33)

P64H

IRQ5

BT_INT

APIC bus

INTC - PCI slot 4 (32/33)

P64H

IRQ6

BT_INT

APIC bus

INTD - PCI slot 4 (32/33)

P64H

IRQ7

BT_INT

APIC bus

INTA - onboard SCSI controller

P64H

IRQ8

BT_INT

APIC bus

AGP - INTA, PCI Slot 1 - INTC, PCI
Slot 2 - INTA, PCI Slot 5 - INTB

ICH2

INTA

INT

APIC bus

PCI Audio - INTA, AGP - INTB, PCI
Slot 1 - INTD, PCI Slot 2 - INTB,
PCI Slot 5 - INTC

ICH2

INTB

INT

APIC bus

BT_INT, PCI Slot 1 - INTA, PCI
Slot 2 - INTC, PCI Slot 5 - INTD

ICH2

INTC

INT

APIC bus

USB - INTA, PCI Slot 1 - INTB, PCI
Slot 2 - INTD, PCI Slot 5 - INTA

ICH2

INTD

INT

APIC bus

Device on Primary IDE Channel

ICH2

IRQ14

INT

APIC bus

Device on Secondary IDE Channel

ICH2

IRQ15

INT

APIC bus

Serial Interrupt from Super I/O

ICH2

SERIRQ

INT

APIC bus

a. In PIC mode, the interrupts signaled to the P64H are chained as INTC to the ICH2.
