Installing Or Replacing Parts And Accessories
Installing SCSI Drives
Chapter 6 131
Verifying Your SCSI Drive
1. Switch on the computer.
2. To enter the SCSI Configuration Utility press Ctrl-C when prompted during the
workstation’s start-up routine.
3. Verify or modify the configuration of your new SCSI hard disk drive.
For more information on configuring a SCSI hard disk drive, refer
to the SCSI User’s Guide.
4. When configuration is complete, exit the SCSI Configuration Utility and re-boot the
computer to save any changes.
additional guide rails
Extra guide rails are supplied for the installation of additional mass storage devices.
These are inside the workstation, three pairs attached on the side of the front access
bays and one pair on the chassis beam. Depending on the device to be installed,
dedicated guide rails are required and are easily recognized by their distinct shape,
markings and color.
SCSI ID = 7 ❐
❐ ■
■ ■
■ ■
■
SCSI ID = 8 ■
■ ❐
❐ ❐
❐ ❐
❐
SCSI ID = 9 ■
■ ❐
❐ ❐
❐ ■
■
SCSI ID = 10 ■
■ ❐
❐ ■
■ ❐
❐
SCSI ID = 11 ■
■ ❐
❐ ■
■ ■
■
SCSI ID = 12 ■
■ ■
■ ❐
❐ ❐
❐
SCSI ID = 13 ■
■ ■
■ ❐
❐ ■
■
SCSI ID = 14 ■
■ ■
■ ■
■ ❐
❐
SCSI ID = 15 ■
■ ■
■ ■
■ ■
■
Table 6-2 Pins to Jumper (Continued)
Drive Style/SCSI ID Pins to Jumper (n)
Number of SCSI
Hard Disks
Standard HP SCSI Configuration
(SCSI ID numbers)
1 ID0
2 ID0, ID1
3 ID0, ID1, ID2
4 ID0, ID1, ID2, ID3
