System Overview
Workstation Description
Chapter 1 15
Mass Storage Seven shelves, supporting:
• Two front-access, third-height 3 1/2-inch drives (one for the floppy
disk drive and one free) (1-inch height)
• Three front-access, half-height, 5 1/4-inch drives (1-inch height); you
can use an adapter tray (available as an accessory) to install two 3
1/2-inch hard disk drives in one of the 5 1/4-inch shelves.
• Two internal 3 1/2-inch hard disk drives (1-inch height)
SCSI Controller Adaptec Ultra 160 SCSI PCI card (optional).
IDE Controller All models include an integrated Ultra ATA-100 controller that supports
as many as four IDE devices.
Graphics Controllers • nVIDIA Quadro2 MXR with TwinView or nVIDIA Quadro Pro
nVIDIA Quadro2 Ex
ATI FireGL 8800
• Matrox Millennium G450-Dual monitor AGP graphics controller with
16MB SGRAM graphics memory (maximum configuration)
• ATI FireGL2 or GL4 3D Graphics Card
Accessory Card Slots One AGP Pro Universal 4X 32-bit slot supporting:
• 1.5V AGP cards (£25W)
• 1.5V AGP Pro Cards (£50W)
The system doesn’t support high-power (i.e., greater than 50W) AGP Pro
and 3.3V AGP cards.
Five 32-bit 33MHz Peripheral Component Interconnect (PCI) slots,
supporting all bridges and multifunction PCI devices. All five PCI slots
comply with PCI Specification 2.2.
• PCI slot 5 contains a LAN interface board.
• PCI slot 4 is for a SCSI interface board (some models only).
LAN Card Lan is now integrated onto the system board. All x2100 models come with
an HP 10/100BT PCI Ethernet Adapter LAN card supporting Wake-On
LAN 9WOL) and PCI Specification 2.2.
Optical Drives Models include one or two of the following IDE drives: CD-ROM, CD-RW,
or DVD-ROM.
Audio CrystalClear CS4299 Audio Codec 97 version 2.1 is integrated on the
system board.
Feature Description
