System Board
System Board Description
Chapter 2
30
System Board Description
This chapter describes the components of the system board including:
•
Memory Controller Hub (MCH)
•
Input/Output Controller Hub (ICH2)
•
FirmWare Hub (FWH)
•
System Bus
Figure 2-1 shows the HP Workstation x2100 system board in detail.
Figure 2-1
HP Workstation x2100 System Board
24.4 cm
9.6 inc
hes
30.5 cm
12 inc
hes
