Installing Or Replacing Parts And Accessories
Removing And Replacing A Hard Disk Drive
Chapter 6
134
boot drive to the upper shelf and install the secondary drive in the lower shelf. This
will insure the cables are positioned correctly. This procedure is not necessary if the
drive is a SCSI drive.
3. Align the guide rails on both sides of the drive with the internal shelf guides and
then slide the drive in until it clicks into position.
NOTE
Avoid trapping or disconnecting the hard disk drive bay thermal sensor cable. If this
cable becomes disconnected, reconnect it to the system board connector marked
THERMAL_SENSOR
(positioned near the IDE and Floppy data cable connectors).
4. Connect the power cable and the data cable to the new hard disk drive. The
connectors are shaped to go in one way only. If you are not sure which connector to
use, refer to “Mass Storage And Optical Device Overview” on page 125.
5. Replace the workstation’s cover (refer to page 119). Reconnect all the power and
telecommunications cables.
