Hp 10/100 tx pci lan interface led descriptions, Table – HP A7818-IE002 User Manual
Page 101
Hardware Components
PCI Cards
Chapter 5
101
HP 10/100 TX PCI LAN Interface LED Descriptions
Table 5-2
LED
Description
Flashing
Steady
Off
10 LNK
Link integrity
Reversed
polarity
Good 10Base-T
connection between
NIC and hub
No connection
between NIC and
hub
100 LNK
Link integrity
Reversed
polarity
Good 100 TX
connection between
NIC and hub
No connection
between NIC and
hub
ACT
Yellow:
Port traffic for
either speed
Network traffic
present
Heavy network traffic
No traffic
