System Overview
Specifications And Characteristics
Chapter 1 20
Specifications And Characteristics
Physical Characteristics
Electrical Specifications
System Processing Unit
Weight: (Standard
configuration as shipped,
excluding keyboard and
display) 14.4 kilograms (31.68 pounds)
Dimensions 47.0cm max. (D) X 21.0cm (W) X 49.0cm (H)
(18.50 inches X 8.26 inches X 19.29 inches)
Footprint 0.09 square meters (1.06 square feet)
Parameter Total Rating
Peak
(15
secs.)
Maximum
per PCI
Slots
32-bit
33MHz
Maximum for AGP Slot
a
Standard
Connector
Extension Total
Input voltage
(Switch select)
100-127
V VAC 200-250
V VAC — — — — —
Input current
(max) 5.5 A 2.5 A — — — — —
Input frequency 50 to 60 Hz — — — — —
Available power 492 W — 100W for PCI slots and AGP Pro slot
Max current at
+12 V 15 A 15 A 0.5 A 1 A 4.2 A 5.2 A
Max current at
-12 V 0.8 A — 0.1 A — — —
Max current at
+3.3V 28 A — 7.6 A 6 A 7.6 A 13.6 A
Vddq
b — — — 2 A
Max current at
+5V 30 A — 5 A 2 A
Max current at
-5V 0.0 A — — — — —
Max current at
+5V stdby
combined with
3.3V stdby 2 A — 1.875 A total on 3.3V stdby
a. The system can draw a maximum of 50W from the AGP Pro slot. The standard part
of the AGP Pro connector supplies 25W (max.), plus 25W from the connector
extension (25W + 25W = 50W). For information about the AGP Pro Universal slot,
see page 33.
b. Only for I/O buffers.
