Quickspecs, What's new, At a glance
Front View:
Rear View:
1.
Cover
1.
Power supply
2.
Four PC2-6400 ECC DDR2 Memory Slots
2.
Mouse connector
3.
Processor Socket (Intel® Xeon®, Core™2, Pentium® or
Celeron®)
3.
NIC 2 Port
4.
USB connectors (2)
4.
Power Supply (400 Watt)
5.
Serial connector
5.
Non Hot Plug Dual Rotor Fans
6.
PCI Express expansion slot 5, low-profile, half-length
6.
Optional 12.7mm DVD-ROM, or DVD-RW Drive for 2
HDD models and optional 9.5mm DVD-ROM, or DVD
combo drive for 4-HDD model
7.
PCI Express expansion slot 4, (optional PCI-X, full-
length)
8.
UID button/LED
9.
Video connector
7.
Two upfront USB connectors
10.
Dedicated Integrated Lights-Out 2 (iLO 2) management
port (optional)
8.
Power Button, UID Button, and Front LED Indicators
9.
Support for up to four Hot Plug SATA or SAS Hard
Drives
11.
NIC 1 Port / Shared iLO 2 Management Port
10.
Two PCI-Express Slots (2 PCI-Express x8 connectors
standard)
12.
Keyboard connector
What's New
New Quad-Core Intel Xeon processors with up to 12 MB L2 cache for 1333MHz Front Side Bus
Support for low-cost Intel Celeron 440 processor
At a Glance
The HP ProLiant DL320 G5p Server is an enterprise rack-optimized server at an entry level price. The highly manageable 1
processor, 1U server is ideal for single-application IT infrastructure, web and edge-of-network applications. The remote
console and virtual KVM offered by the embedded iLO-2, coupled with the management features of SIM and deployment
capabilities of SmartStart and other ProLiant Essentials software, give the DL320 G5p enterprise-class management
features. Optional upgrades provide support for hot-plug SAS drives and/or up to 4 SAS or SATA drives, and gives the
DL320 G5p the flexibility to meet the needs of your datacenter. Plus, you get the cost-effective solution of a single-processor
platform with the performance advantages of dual-core or quad-core.
Processor:
Quad-Core Intel® Xeon® 3300 processor sequence
QuickSpecs
HP ProLiant DL320 Generation 5p
Overview
DA - 12854 Worldwide QuickSpecs — Version 12 — 5-28-2008
Page 1
