Chapter 5 Basic Operations — IMAGE
Setting image effects
Four types of effects, paint, monochrome color, mosaic, and defocus can be set to the KEY1FILL, KEY2FILL, PGM/A, and PST/B bus sources.
f The [Key1] tab can set bus sources of KEY1FILL, the [Key2] tab can set bus sources of KEY2FILL, and the [BKGD] tab can set bus sources of PGM/A
and PST/B.
f Press the button on the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 to enable the menu setting of the relevant bus.
Paint effect
Make the gradation of image level coarse in order to add painting like effect.
1
Select the / button → [IMAGE] → [Key1]/[Key2]/[BKGD] tab.
2
Select an item in [Paint] in the [Effect1]/[A Effect1]/[B Effect1] column.
[On] Enables the paint effect.
[Off] Disables the paint effect.
3
Set [Paint Y] and [Paint C] in the [Effect1]/[A Effect1]/[B Effect1] column.
[Y] Adjusts the level gradation of luminance component. When set to [0], the paint effect is disabled.
[C] Adjusts the level gradation of chrome component. When set to [0], the paint effect is disabled.
Monochrome color effect
Make the color components of an image monochrome color.
1
Select the / button → [IMAGE] → [Key1]/[Key2]/[BKGD] tab.
2
Select an item in [Mono] in the [Effect2]/[A Effect2]/[B Effect2] column.
[On] Enables the monochrome color effect.
[Off] Disables the monochrome color effect.
3
Set [Mono Hue] and [Mono Sat] in the [Effect2]/[A Effect2]/[B Effect2] column.
[Hue] Adjusts the hue of the monochrome color effect.
[Sat] Adjusts the saturation of the monochrome color effect.
Mosaic/defocus effect
Add the mosaic or defocus effect to an image.
1
Select the / button → [IMAGE] → [Key1]/[Key2]/[BKGD] tab.
2
Select a mode in the [Mosaic/Defocus]/[A Mosaic/Defocus]/[B Mosaic/Defocus] column.
[Off] Disables the mosaic or defocus effect.
[Mosaic] Enables the mosaic effect.
[Defocus] Enables the defocus effect.
3
Set [Level] in the [Mosaic/Defocus]/[A Mosaic/Defocus]/[B Mosaic/Defocus] column.
f Adjust the amount of the mosaic effect and the defocus effect. When set to [0.0], the mosaic effect and the defocus effect are disabled.
@ @ NOTE
t If transitions are performed while [PGM‑A/PST‑B] (flip‑flop system) is selected using the button on the top menu → [OPERATE] →
[Transition] tab → [Bus Mode] column → [Bus Mode], the PGM/A bus and the PST/B bus will swap. At this time, the buses with image effects will also
swap.
Executing image effects
Output of image effects is delayed by one frame compared to normal output because they are created using DVE (Digital Video Effect).
Even if effects are enabled only for either the PGM/A bus or the PST/B bus by pressing the button, the output of both buses are delayed by one
frame.
