– 119 –
Chapter 6 Input/Output Signal Settings — Setting input signals
Setting input signals
[SDI IN 1] to [SDI IN 32] are used for SDI signal input.
[DVI IN 1] and [DVI IN 2] are used for DVI-D signal input.
f
To configure the input signal settings, select the
→
[SDI IN]/[DVI IN].
@
@
NOTE
t
There is a limitation on the function when the switcher mode is set to the 3G mode or the 4K mode. For details on the 3G mode or the 4K mode, refer
to “Difference of function for each mode” (page 164).
r
List of settings by input signal
f
“
l
” indicates enabled, and “―” indicates disabled.
[FS]
[Mode]
[Frame delay]
[Freeze Mode],
[Freeze]
Source name
setting*
1
Color
corrector*
2
[Up Converter]
[SDI IN 1] - [SDI IN 24]
l
l
―
l
l
―
―
[SDI IN 25], [SDI IN 26], [SDI IN
29], [SDI IN 30]
l
l
―
l
l
l
―
[SDI IN 27], [SDI IN 28], [SDI IN
31], [SDI IN 32]
l
l
l
l
l
l
l
[DVI IN 1], [DVI IN 2]
Always enabled
―
―
l
l
―
―
*1 For details, refer to “Setting the source name” (page 132).
*2 For details, refer to “Color corrector” (page 86).
Setting the frame synchronizer
The frame synchronizer can be set enabled/disabled for each input.
f
The frame synchronizer for DVI input is always enabled, and setting cannot be changed.
1
Select the
→
[SDI IN]
→
[Frame Buffer] tab.
2
Select an item in [FS] in the [SDI IN 1] to [SDI IN 32] columns.
[Strict]
Enables the frame synchronizer function. When the signal different from the system format is input, the screen becomes
black.
[Acceptable]
Enables the frame synchronizer function. Even when the signal different from the system format is input, the screen does
not become black. The images output at this time may be disturbed. VANC and HANC data will be deleted.
[Off]
Disables the frame synchronizer function.
f
When the output signal phase is set to [0H], [FS] cannot be set to [Off].
For details, refer to “Setting the output phase” (page 141).
@
@
NOTE
t
Line synchronizer function is active while the frame synchronizer function is set to [Off].
t
The line synchronizer function automatically adjusts the input video signal phase to the horizontal sync signal phase.
For details, refer to “Setting the output phase” (page 141).
t
The screen becomes black in the following combinations even if [Acceptable] is selected in [FS] in the [SDI IN 1] to [SDI IN 32] columns.
- When the system format frequency is 59.94i, 50i, 29.97Psf, or 25Psf, and the input signal frequency is 59.94p or 50p
- When the system format frequency is 59.94p or 50p, and the input signal frequency is 59.94i, 50i, 29.97Psf, or 25Psf
Setting the input mode
The mode can be set for each input only when HD is selected as the system format.
The input mode is always set to [Normal] when SD is selected as the system format.
1
Select the
→
[SDI IN]
→
[Frame Buffer] tab.
2
Select an item in [Mode] in the [SDI IN 1] to [SDI IN 32] columns.
f
Set the input mode.
[Normal]
Input signals in conformity with the system format take effect.
[Dot by Dot]
When SD signals with the same frame rate as the system format have been input, they are input on a dot by dot (actual
size) basis without up-conversion. (This can be set only when the system format is 1080i)
In this mode, there is minimal deterioration in the image quality and, as such, the mode is used to combine sources in
the SD format using the PinP function.
[U/C]
When HD is selected as the system format and SD signals with the same frame rate as the system format have been
input, the signals are up-converted. When HD signals are input, the screen becomes black.
f
This item is displayed when the [SDI IN 27]/[SDI IN 28]/[SDI IN 31]/[SDI IN 32] column is selected.
[Auto]
Input signals in conformity with the system format are enabled. When HD is selected as the system format, whether the
input signal is HD or SD is determined. The HD signal is handled as [Normal], and the SD signal is handled as [U/C].
In [Auto] mode, the images may be disturbed when the input signals are switched.
f
This item is displayed when the [SDI IN 27]/[SDI IN 28]/[SDI IN 31]/[SDI IN 32] column is selected.
