– 201 –
Chapter 12 Appendix — Setting menu table
[Load Picture] tab
Column Item Setting item Default
[SDI IN 1] - [SDI
IN 32], [DVI IN
1], [DVI IN 2],
[Still 1V] - [Still
4V], [Still 1K] -
[Still 4K], [Clip
1V] - [Clip 4V],
[Clip 1K] - [Clip
4K], [CBGD
1], [CBGD 2],
[CBAR], [Black]
[Type] [Default], [User], [Picture] [Default]
[Name] ― ―
― ― ―
― ― ―
[Load from
Local]
([Load from Local]
screen)
―
[MV Name] tab
Column Item Setting item Default
[SDI IN 1] - [SDI
IN 32], [DVI IN
1], [DVI IN 2],
[Still 1V] - [Still
4V], [Still 1K] -
[Still 4K], [Clip
1V] - [Clip 4V],
[Clip 1K] - [Clip
4K], [CBGD
1], [CBGD 2],
[CBAR], [Black]
[Type] [Default], [User], [Same
as Panel]
[Same as
Panel]
[Name] ― ―
[SOURCE LINK] (function menu)
[Key Assign] tab
The assignment setting screen is displayed.
[AUX Bus Link] tab
Column Item Setting item Default
[Link 1] [AUX1/2 Link] -
[AUX9/10 Link]
[Off], [On] [Off]
Column Item Setting item Default
[Link 2] [AUX11/12 Link]
- [AUX15/16
Link]
[Off], [On] [Off]
[OPERATE] (function menu)
[Transition] tab
Column Item Setting item Default
[Page Mode] [2nd Page
Button], [3rd
Page Button]
[Normal], [Page Lock] [Normal]
[Bus Mode] [Bus Mode] [A/B], [PGM-A/PST-B],
[PGM-B/PST-A]
[PGM-A/
PST-B]
[Time Unit] [Time Unit] [Sec/Frame], [Frame] [Sec/Frame]
[FTB] [FTB On] [Off], [On] [Off]
Source [Still1] - [Still4], [Clip1]
- [Clip4], [CBGD 1],
[CBGD 2], [White],
[Black]
[Black]
[Time] [0] - [999] ―
[AUX Trans] [AUX1] - [AUX4] [Off], [On] [Off]
Column Item Setting item Default
[Trans Time] [AUX1] - [AUX4] [0] - [999] ―
[MECHG] tab
Column Item Setting item Default
[MainPanel],
[SubPanel1],
[SubPanel2]
[1st Line] [ME1], [ME2] [ME1]
[2nd Line] [ME1], [ME2] [ME2]
[Key] tab
Column Item Setting item Default
[Key Source
Preset]
[Source Preset] [Enable], [Disable] [Enable]
[Keyer Link] [Enable], [Disable] [Disable]
[MENU LOCK] (function menu)
[Menu Lock] tab
Column Item Setting item Default
[Menu Lock] [BUTTON
INHIBIT]
[Off], [On] [Off]
[XPT ASSIGN] [Off], [On] [Off]
[SOURCE
NAME]
[Off], [On] [Off]
[SOURCE
LINK]
[Off], [On] [Off]
[OPERATE] [Off], [On] [Off]
