Chapter 5 Basic Operations — Background transition
f The bus tallies on the right of the PGM/A bus crosspoint buttons and the PST/B bus crosspoint buttons indicate the output status of the program
bus.
Lighting color Description
Red Lights when the relevant bus is included in the on-air output.
Amber Lights when the relevant bus is not included in the on-air output but included in the program output.
Off Lights when the relevant bus is included in neither the on-air output nor the program output.
r Setting the transition time
1
Select the / button → [BKGD] → [Transition] tab.
2
Set [Time] in the [Transition] column.
f Set the transition time.
@ @ NOTE
t The units used for time display of the unit can be set to either in seconds/frame or in frames. (page 136)
r Setting the start and end points of a transition
1
Select the / button → [BKGD] → [Transition] tab.
2
Set [Start Point] and [End Point] in the [Transition] column.
[Start Point]
Sets the start point for the background transition.
The background transition will start after the start point of the manual transition or the auto transition when a value
larger than 0 is set for [Start Point]. At this time, the lamp for start point of the fader lever will blink in the transition status
display.
[End Point]
Sets the end point for background transition.
The background transition will complete before the end point of the manual transition or the auto transition when a value
larger than 0 is set for [End Point]. At this time, the lamp for end point of the fader lever will blink in the transition status
display.
f While the is lighting up, the settings of [Start Point] and [End Point] are disabled.
r button setting
Sets the operation of the background transition when both the button and the button are set ON.
1
Select the / button → [BKGD] → [Transition] tab.
2
Set [NAM]/[CMIX] in the [Trans Type] column.
[NAM]
Switches the images in the A bus/B bus with non-additive mixing.
It will be high luminance with the A bus at 100% and the B bus at 100% when the fader lever is positioned midway.
[CMIX]
It will perform the MIX mixing (color mix mixing) set in the [CMIX Color] column at the midway of the images of A bus/B
bus.
3
Adjust the color.
[Hue], [Sat], [Lum] or [Color Palette] is set in the [CMIX Color] column.
