Chapter 12 Appendix — Setting menu table
[MENU LOCK] (function menu)
[Menu Lock] tab
Column Item Setting item Default
[Menu Lock] [SYSTEM] [Off], [On] [Off]
[MAIN FRAME] [Off], [On] [Off]
[CTRL PANEL] [Off], [On] [Off]
[PERIPHERAL] [Off], [On] [Off]
[MAINTENANCE] [Off], [On] [Off]
button (top menu)
[SDI IN] (function menu)
[Frame Buffer] tab
Column Item Setting item Default
[SDI IN 1] - [SDI
IN 26], [SDI IN
29], [SDI IN 30]
[Mode] [Normal], [Dot by Dot] [Normal]
[FS] [Off], [Strict], [Acceptable] [Strict]
[Freeze mode] [Frame], [Field] [Frame]
[Freeze] [Off], [On] [Off]
[Frame delay] ― ―
[SDI IN 27],
[SDI IN 28],
[SDI IN 31],
[SDI IN 32]
[Mode] [Normal], [Dot by Dot],
[U/C], [Auto]
[Auto]
([Normal])
[FS] [Off], [Strict], [Acceptable] [Strict]
[Freeze mode] [Frame], [Field] [Frame]
[Freeze] [Off], [On] [Off]
[Frame delay] [0F] - [8F] [0F]
[Status] tab
Column Item Setting item Default
[SDI IN 1] - [SDI
IN 32]
[Format] ― ―
[Audio] ― ―
[Up Converter] tab
Column Item Setting item Default
[SDI IN 27],
[SDI IN 28],
[SDI IN 31],
[SDI IN 32]
[Scale] [Squeeze], [Edge Crop],
[Letter Box]
[Squeeze]
[Motion Detect] [1] - [5] [3]
[Sharp] [1] - [5] [3]
[Size] [100] - [110] [100]
[Edge Crop
Pos.]
[Center], [Right], [Left] [Center]
[DVI IN] (function menu)
[Frame Buffer] tab
Column Item Setting item Default
[DVI IN 1], [DVI
IN 2]
[Scale] [Full], [Fit-V], [Fit-H] [Full]
[Freeze mode] [Frame], [Field] [Frame]
[Freeze] [Off], [On] [Off]
[Limited] [Off], [On] [Off]
[Status] tab
Column Item Setting item Default
[DVI IN 1], [DVI
IN 2]
[Size] ― ―
[Dot Clock] ― ―
[H-Frequency] ― ―
[V-Frequency] ― ―
[SDI OUT] (function menu)
[Assign] tab
The assignment setting screen is displayed.
[Down Converter] tab
Column Item Setting item Default
[SDI OUT 14],
[SDI OUT 16]
[Limit] [Off], [108%], [104%],
[100%]
[Off]
[Enable] [Off], [On] [Off]
[Scale] [Squeeze], [Edge Crop],
[Letter Box]
[Squeeze]
[Delay] [90H] ([75H]), [1F] [90H]
([75H])
[Sharp] [1] - [5] [3]
[C/C IN 25‑30], [C/C IN 31‑32] (function menu)
[SDI IN 25] to [SDI IN 32] tabs
Column Item Setting item Default
[Operation] [Enable] [Off], [On] [Off]
[Limit] [Off], [108], [104], [100] [Off]
[Process] [Y-Gain] [0.0] - [200.0] [100.0]
[Pedestal] [ − 20.0] - [20.0] [0.0]
[C-Gain] [0.0] - [200.0] [100.0]
[Hue] [0.0] - [359.9] [0.0]
[Colorimetry] [Off], [On] [Off]
Column Item Setting item Default
[Tone1 Black] [Red] [ − 10.0] - [108.0] [0.0]
[Green] [ − 10.0] - [108.0] [0.0]
[Blue] [ − 10.0] - [108.0] [0.0]
[RGB Link] [Off], [On] [Off]
[Tone2 Gray L] [Red] [ − 10.0] - [108.0] [33.3]
[Green] [ − 10.0] - [108.0] [33.3]
[Blue] [ − 10.0] - [108.0] [33.3]
