Chapter 11 Specifications — Dimensions

Dimensions of the Control Panel AV‑HS60C4

Unit: mm (inch)

160 (6-5/16)

400 (15-3/4)

97.5 (3-27/32)

656 (25-27/32)

132 (5-7/32)
