– 182 –
Chapter 11 Specifications — Specifications
Control terminal
Compatible with 100Base-TX and AUTO-MDIX (For Main Frame AV-HS60U1/AV-HS60U2 connection)
f Connection cable (supplied with AV-HS60C4): LAN cable (CAT5E), straight cable, STP (Shielded Twisted Pair), 10 m
(32.8 ft)
f Connector: RJ-45
* When connected to the terminal, no video will be displayed on the Menu Panel AV-HS60C3.
Used only for the Menu Panel AV-HS60C3
f Connector: DVI-D
f Cannot be displayed on a DVI-D monitor because an independent signal format is used.
f Cannot be used concurrently with a DVI-D monitor (computer) connected to the terminal. Select with the
display selector switch.
terminal Used for displaying menus to the DVI monitor (computer)
f Connector: DVI-D
f Monitor resolution: 1366 × 768 compatible monitor
f Cannot be used concurrently with the
terminal For DVI monitor (computer) menu operation
f Connector: USB (Type A, female)
f Cannot be used for the Menu Panel AV-HS60C3.
Display selector switch Switch for selecting
terminal RS-422 control terminal
For master connection for controlling external devices
f Connector: D-sub 9-pin (female), inch screw
terminal RS-232 control terminal
For external device control connections
f Connector: D-sub 9-pin (male), inch screw
terminal GPI IN: 8 inputs, general-purpose, photocoupler sensing
ALARM OUT: 1 output, open collector output (negative logic)
GPI OUT: 10 outputs, selected from general purpose, tally
Open collector output
f Connector: D-sub 25-pin (female), inch screw
f Logic is switchable by menu.
ME number 2ME
Other
Ambient operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 10% to 90% (no condensation)
Dimensions (W × H × D) 656 mm × 160 mm × 400 mm (25-27/32 inches × 6-5/16 inches × 15-3/4inches) (excluding protrusions)
Mass Approx. 15.0 k ] (33.1 lbs.) (excluding accessories)
r For AV‑HS60C4
Inrush current, measured according to European standard EN55103-1, on initial switch-on: 3 A, after a supply interruption of 5 s: 25 A (Each mains
input)
Menu Panel AV‑HS60C3
Power supply
DC e 12 V/0.54 A
* Supplied from AV-HS60C1/AV-HS60C2/AV-HS60C4 using supplied cable
Power consumption
6.48 W
indicates safety information.
terminal Used only for the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4
f Connector: DVI-D
f Because an independent signal format is used, DVI-D source cannot be displayed.
f Cannot be used concurrently with a DVI-D monitor connected to the terminal of the Control Panel AV-HS60C1/
AV-HS60C2/AV-HS60C4. Set the display selector switch of the Control Panel AV-HS60C1/AV-HS60C2/AV-HS60C4 to
the
Ambient operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 10% to 90% (no condensation)
Dimensions (W × H × D) 290 mm × 177 mm × 46.1 mm (11-13/32 inches × 6-31/32 inches × 1-13/16 inches) (excluding protrusions)
4RU
Mass AV-HS60C3: Approx. 1.7 k ] (3.7 lbs.) (excluding accessories)
