Communications D - 10

Modbus Data Tables

The data tables are shown below. The types of data are as follows: Reference data, monitor data, broadcast data, and parameter
data.

Reference Data

The reference data table is shown below. Reference data can be read and written to.

Table D.4 Reference Data

Register No.

Contents

0000H

Reserved

0001H

Input terminal status

Bit 0

Run Forward command

Run = 1 Stop = 0

Bit 1

Run Reverse command

Run = 1 Stop = 0

Bit 2

External fault:

Fault (EFO) = 1

Bit 3

Fault reset:

Reset command = 1

Bit 4

ComNet

Bit 5

ComCtrl

Bit 6

Multi-function digital input command 3 (terminal S3)

Bit 7

Multi-function digital input command 4 (terminal S4)

Bit 8

Multi-function digital input command 5 (terminal S5)

Bit 9

Multi-function digital input command 6 (terminal S6)

Bit A

Multi-function digital input command 7 (terminal S7)

Bit B

Multi-function digital input command 8 (terminal S8)

Bits C to F Not used

0002H

Frequency reference (Set units using parameter o1-03)

0003H to 0005H

Not used

0006H

PID Setpoint

0007H

Analog output 1 (terminal FM) setting (-11V = 726 to 11V = 726)

→ 10V = 660

0008H

Analog output 2 (terminal AM) setting (-11V = 726 to 11V = 726)

→ 10V = 660

0009H

Multi-function contact output settings

Bit 0

Digital output 1 (terminal M1-M2):

ON = 1

OFF = 0

Bit 1

Digital output 2 (terminal M3-M4):

ON = 1

OFF = 0

Bit 2

Digital output 3 (terminal M5-M6):

ON = 1

OFF = 0

Bits 3 to 5

Not used

Bit 6

Set Fault contact (terminal MA-MC) output using bit 7: ON = 1 OFF = 0

Bit 7

Fault contact (terminal MA-MC):

ON = 1OFF = 0

Bits 8 to F

Not used

000AH to 000EH Not used

000FH

Reference selection settings

Bit 0

Not used

Bit 1

Input PID setpoint 1: Enabled 0: Disabled

Bits 3 to B

Not used

C

Broadcast data terminal S5 input: Enabled = 1 Disabled = 0

D

Broadcast data terminal S6 input: Enabled = 1 Disabled = 0

E

Broadcast data terminal S7 input: Enabled = 1 Disabled = 0

F

Broadcast data terminal S8 input: Enabled = 1 Disabled = 0

000CH to 000FH Refer to Table D.6, broadcast data, when using bits 000CH through 000FH

Note:Write 0 to all unused bits. Do not write data to reserved or “Not Used” registers and bits.
