Grass Valley EDIUS Pro v.7.20 - Manual (Page 95)

73
[System Settings]
EDIUS - Reference Manual
3 Set each item.
4 Click [OK].
You can continue to set other items by clicking [Apply].
K2 (FTP) Connection Settings
Set up FTP server connections before importing sources on the K2 Media server.
1 Click [Settings] on the menu bar, and click [System Settings].
2 Click the [Importer/Exporter] tree, and click [K2 (FTP)] → [FTP Server].
3 Set each item.
4 Click [OK].
You can continue to set other items by clicking [Apply].
[FTP setting] Dialog Box
0
K2 Browser Settings
Set items that are allowed when connecting to the K2 Media server.
1 Click [Settings] on the menu bar, and click [System Settings].
2 Click the [Importer/Exporter] tree, and click [K2 (FTP)] → [Browser].
[Source Folders] This is the list of references that is displayed in the source browser folder
view.
Infinity sources can be handled as clips by the source browser by copying
them to the hard disk with the folder structure in the device held intact.
Click [Add] to set the reference folder. To delete a reference folder that has
been set, select the folder and click [Remove].
[Server List] This is the list of K2 Media servers that is displayed in the source browser
folder view.
[Add] Click this item to display the [FTP setting] dialog box for adding connection
servers.
[FTP setting] Dialog Box 0 P73
[Delete] Delete servers from [Server List].
[Modify] Change the server settings.
[Move Up]/[Move Down] Sort the list.
Select a server from [Server List] and move the selected server one place up
or down with each click of [Move Up] or [Move Down].
[Setting] Display the settings of the connection selected in [Server List].
[Name] Enter the name of the server to display in the folder view.
[Address] Enter the address of the server.
[Folder] The address of the bin is entered. Normally, there is no need to change the
frame rate.
[Username]/[Password] Enter the user name and password required when making the connection.
[Connection Test] Click this item to test the connection to the FTP server using the currently
entered user name and password.
