Grass Valley EDIUS Pro v.7.20 - Manual (Page 94)

Edit Settings
72 EDIUS - Reference Manual
2 Click the [Importer/Exporter] tree, and click [GXF].
3 Set each item.
4 Click [OK].
You can continue to set other items by clicking [Apply].
[FTP setting] Dialog Box
0
[RED]
Set an image quality for playback of sources in RED format.
1 Click [Settings] on the menu bar, and click [System Settings].
The [System Settings] dialog box appears.
2 Click the [Importer/Exporter] tree, and click [RED].
3 Set each item.
4 Click [OK].
You can continue to set other items by clicking [Apply].
[Infinity]
Set the reference folder when source files in Infinity devices are imported from the source browser window.
1 Click [Settings] on the menu bar, and click [System Settings].
2 Click the [Importer/Exporter] tree, and click [Infinity].
[Server List] Display a list of addresses of FTP servers set as export destinations.
[Add] Click this item to display the [FTP setting] dialog box for adding connection
servers.
[FTP setting] Dialog Box 0 P72
[Delete] Delete servers from [Server List].
[Modify] Change the server settings.
[Move Up]/[Move Down] Sort the servers.
Select a server from [Server List] and move the selected server one place up
or down with each click of [Move Up] or [Move Down].
[Settings] Display the settings of the connection selected in [Server List].
[Name] Enter the name set for the server.
[Address] Enter the IP address or server name of the FTP server.
[PortNo] Enter the port number. The default port number is 21.
[Directory] Enter the directory name of the export destination.
[Username]/[Password] Enter the user name and password required when making the connection.
[Connection Test] Click this item to test the connection to the FTP server using the currently
entered user name and password.
[Preview Quality] Set the playback image quality.
Select [1/1] to retain the source resolution.
Select [1/2], [1/4], [1/8], or [1/16] to reduce the image quality to 1/2, 1/4, 1/8,
or 1/16 of the source horizontal resolution respectively.
