Interaction with STRATUS
462
EDIUS - Reference Manual
2 Select a device preset that supports capturing in K2 Clip format, and click [OK].
The [K2 Ingest Setting] dialog box appears.
[K2 Ingest Setting] Dialog Box
2
Alternative
• Click [Capture] on the menu bar, and click [Device Preset Name] to display the device preset.
• Click the device preset name ([Input Preset 1] to [Input Preset 8]) to display the device preset. (By default, [Input
preset 2] to [Input Preset 8] are not displayed. Before performing the operation, set to display the buttons in the
preview window.)
• Displaying the device preset assigned to the input preset 1:
[F2]
• Displaying the device preset assigned to the input preset 2:
[F3]
• Displaying the device preset assigned to the input preset 3:
[F4]
3 Configure the settings including the save destination and reel name for the source to be captured, and then
click [OK].
When you capture sources from a device that supports deck control by EDIUS, you can operate the camera using the
operation buttons on the Player.
When you capture sources from a device that does not support deck control by EDIUS, proceed to step 5.
4 Play back the source to capture, and set the In and Out points.
5 Click [Capture] on the Player.
The [K2 Ingest Setting] dialog box appears.
6 Change the clip name as necessary.
Capturing starts. The [Capture] dialog box appears.
For a device that supports deck control by EDIUS, capturing ends automatically at the Out point. Click [Stop] in the
[Capture] dialog box to stop capturing halfway through the process. If you want to continue capturing, repeat steps 4
through 6.
For a device that does not support deck control by EDIUS, click [Stop] in the [Capture] dialog box to stop capturing and
stop the playback on the device. If you want to continue capturing, cue up to the part you want to capture and then
repeat steps 5 and 6.
The icon
indicating that the system is generating a file is displayed on the clip that is being captured in the source
browser.
The captured clip is registered in the bin.
2
Alternative
• Press [F9] on the keyboard after step 4.
3
•
During capture, you can add a marker with a comment to the source clip.
• During the capturing process, another EDIUS client on the same network can perform edit while recording by
loading the captured data.
Loading K2 Clip Files to Be Managed by the K2 Media Server
• If you want to change the save destination or reel name halfway through the process, for example, when you
replace the tape, click [Capture] on the menu bar and, click [K2 Ingest Setting].
1
Note
• If only the audio is captured, it is not displayed as a clip in the source browser window. A WAV file is saved in the
project folder.
