Grass Valley EDIUS Pro v.7.20 - Manual (Page 483)

461
Interaction Function with STRATUS
EDIUS - Reference Manual
4 Capture in K2 Clip format.
Capture sources in K2 Clip format.
Capturing in K2 Clip Format
0 P461
Batch Capturing in K2 Clip Format 0 P463
Detailed Codec Settings when Capturing in K2 Clip Format
The codec settings that support capturing in K2 Clip format are as follows.
[Settings - MPEG2 for K2 Clip] Dialog Box 0 P461
[Settings - XDCAM HD422 Compatible] Dialog Box 0 P100
[Settings - XDCAM EX Compatible] / [Settings - XDCAM HD Compatible] Dialog Box 0 P100
[Settings - MPEG IMX] Dialog Box 0 P100
[Settings - MPEG2 for K2 Clip] Dialog Box
0
Capturing in K2 Clip Format
Capture sources in K2 Clip format.
1
Note
• Analog devices or devices that are connected via an HDMI terminal cannot be controlled from EDIUS. When you
capture sources from a device that does not support deck control by EDIUS, you need to cue up to the part you want
to capture beforehand.
1 Click [Capture] on the menu bar, and click [Select Input Device].
The [Select Input Device] dialog box appears, and the list of the device presets you registered in the system settings is
displayed.
[Bit Rate] Select a bitrate type.
[CBR] sets a fixed transfer rate, allocating a fixed number of bits during the
encoding process. Select a bitrate from the [Average] list. You can also enter
a value directly.
[VBR] sets a variable transfer rate, altering the number of assigned bits
according to the complexity of the movement or image quality. Compared
with [CBR], the media volume can be used more efficiently, and this enables
more consistent image quality overall. Select a bitrate from the [Average] and
[Max] lists. You can also enter a value directly.
[Quality/Speed] Select quality from the list.
[GOP Structure] For MPEG, a certain number of frames is considered as a group, and opera-
tions such as compression/enlargement and cut editing are performed on a
GOP basis. A GOP comprises “I frame”, “P frame” and “B frame”. The I frame
allows images to be reproduced independently, the P frame is for recording
and reproducing only the differences with the preceding image, and the B
frame reproduces images from the differences in the preceding and following
images. Select I, P and B frame patterns of the GOP from the list. Normally,
select [IBBP].
[I-Frame Only] is comprised of only I-pictures. Editing is made easier, but the
amount of data increases in size.
[Picture count] Set the number of frames included in a group.
[Closed GOP] Check this item to complete information within each GOP. Although the
amount of data increases, the video can be re-edited using software that sup-
ports GOP-based editing. Normally, leave this item unchecked.
[Chroma Format] Select a YUV pixel format from the list.
[Profile/Level] Select a profile & level. If [Chroma Format] is [4:2:0] and [4:2:2], the profile
will be set to Main Profile and 422Profile, respectively. The level for SD
image quality will be Main Level, and the level for HD image quality will be
High Level. The profile & level changes according to the format selected in
[Chroma Format].
