Applying Effects
328
EDIUS - Reference Manual
(2)
Drawing buttons
: Drag the mouse to draw a rectangle. Drag the mouse with [Shift] on the
keyboard held down to draw a square.
: Drag the mouse to draw an ellipse. Drag the mouse with [Shift] on the
key board held down to draw a circle.
: Draw a free shape using Bezier curve.
(3)
[Undo]/[Redo]
: Undo an operation.
: Redo the undone operation.
(4)
Edit buttons
Cut, copy, paste, and delete a selected path.
(5)
Function menu
[Apply Mask]
Switch the enable/disable setting for mask temporarily.
[Background]
Switch the show/hide setting for the transparent grid if the transparency is set
for outside and inside of the mask.
[Motion Path]
Switch the show/hide setting for the path if the position is changed by key
frame and the setting is enabled.
[Grid]
Switch the show/hide setting for the grid.
[Guide]
Switch the show/hide setting for the underscan, overscan, title safe, horizon-
tal/vertical center line.
[Stereoscopic]
Displayed only in the stereoscopic edit mode. The display can be switched to
L side only, R side only or to the L and R sides blended.
(6)
Zoom factor
Change the zoom factor by entering a value or selecting a value from the list.
(7)
Preview
Display a preview of the image being edited.
Select a path to display a handle or anchor to modify the path.
(8)
Stretch handles
Move the cursor to the operation handles at the corners and at the middle of
the lines to resize the area.
(9)
Anchor
Indicate the reference point of the path. This point is a reference point for the
rotation center and for stretching. Drag with [Ctrl] on the keyboard held down
to change the position.
(10)
Rotation handle
Move the cursor and drag the rotation handle to rotate the image.
(11)
[Inside]/[Outside]
Set video filters for outside and inside the path.
[Opacity]
Use these settings to configure the transparency inside and outside of the
path.
[Filter]
Check this item to enable the video filters set inside and outside the path.
: Click this button to select a video filter.
: Click this button to configure the video filter setting for outside and
inside the path.
[Strength]
The strength of video filter effects can be set.
